[Solved] masterflat correcting to much?

4 Posts
2 Users
1 Likes
1,742 Views
(@jeroenm)
Red Giant
Joined: 7 years ago
Posts: 31
Topic starter

Hello all,

not really a APP problem - it's doing it's job very well, but I ran into a major problem I can't get solved. Lately I'm having problems with the calibration process with my flats. I didn't change anything in my setup, the process of calibration or anything else for that matter. It look like my flats are over correcting the dust bunnies in my image train. I have 2 kinds of "donuts": small ones that are close te the sensor of my CCD, a bit dark and are visible in the master flat. The second ones are larger, have a bit less contrast, are bigger in size and are almost not visible in the master flat.



After calibrating the lights with a master dark and master flat, registering and stacking I got a really nice M101 with only 5 hours of data (luminance) with my SBIG STF8300M and 10" F5 Newton. A bit of gradient, but that's normal considering the light pollution I'm stuck with. After applying the "light pollution correction" in APP the result has strange gradients in the background I can't get rid of. After a lot of try-and-error with different settings, a new set of flats etc I finally figured out that my flats are causing this problem.



Not the way to go (I know) I tried applying the light pollution correction to my master flat to see what's going on with the flats. As you can see in the attached screenshot it's full of small donuts (dust close to the sensor) and larger donuts caused by dust on the luminance filter. The smaller donuts are corrected well, but it looks like the larger ones are a kind of over corrected and now appear as bright cirkels in my stack. To make the whole picture complete I added 4 pictures: the final stack before correction, the stack after correction with "light pollution correction", the master flat and the master flat after "light pollution correction". Thus last one is really showing the donuts. Besides APP I also tried calibration in 2 other programs with the same result. Anyone having any ideas?

stack zonder DBE
Schermafbeelding 2018 03 27 om 22.39.48
masterflat
masterfalt DBE


ReplyQuote
(@mabula-admin)
Universe Admin
Joined: 7 years ago
Posts: 4366


Hi Jeroen @jeroenm,

APP 1.059 does have a problem with flat-field correction on some data sets. This will be corrected in APP 1.060 which will have a very big upgrade of the complete calibration engine 😉

Since you get the same results in other applications, the source of your problem is most likely to be found in how shoot your flats possibly. How are you making them? What kind of exposure time do you use?

Perhaps, you were able to locate the source of the problem in the mean time?

Kind regards,

Mabula



ReplyQuote
(@jeroenm)
Red Giant
Joined: 7 years ago
Posts: 31
Topic starter

Hi Mabula,

the problem is already solved. Looks like I had a lot of moist in my imagetrain which caused the problem. I make my flats with Sequence Generator Pro, using the ADU value of the camera and this never led to any problems. Really looking forward to the latest version of APP!

kind regards,

Jeroen





Mabula-Admin reacted
ReplyQuote
(@mabula-admin)
Universe Admin
Joined: 7 years ago
Posts: 4366

Posted by: Jeroen

Hi Mabula,

the problem is already solved. Looks like I had a lot of moist in my imagetrain which caused the problem. I make my flats with Sequence Generator Pro, using the ADU value of the camera and this never led to any problems. Really looking forward to the latest version of APP!

kind regards,

Jeroen



Excellent @jeroenm,

I am glad you found the source of the problem 😉

Cheers,

Mabula
