Taurus widefield - Problems with LPC


(@skanker)
Main Sequence Star Customer
Joined: 4 years ago
Posts: 86
Topic starter

Hello from Austria!



My stack shows a strong gradient and i don't get a proper correction in the tool.

Taurus 105mm St



I uploaded the stack for you: https://drive.google.com/drive/folders/1PRxmRdlqNGAdA47VoR4w83qEz6rgTTiX?usp=sharing

Is the material unusable?



CS Gernot




ReplyQuote
(@wvreeven)
Galaxy Admin
Joined: 4 years ago
Posts: 1782


@skanker Ouch that is a nasty gradient. I am downloading the file right now to see what I can do with it.


Skanker liked
ReplyQuote
(@wvreeven)
Galaxy Admin
Joined: 4 years ago
Posts: 1782


@skanker Whatever I try, I keep on getting strange artifacts at the bottom of the image. Did you process each individual panel before combining them to the mosaic and, if yes, what did you do?


ReplyQuote
(@vincent-mod)
Quasar Admin
Joined: 5 years ago
Posts: 4919


I had a look as well and the trick here is to gradually set Light pollution correction boxes on the edges of more extreme gradients. I started with 5 around the edges and slowly adding more and checking what APP makes of it. There is quite a lot of gradients, both due to light pollution but also in color. So I creeped up onto the patches of color as well as dark and light spots. To make everything as visible for me as possible, I cranked up the saturation and stretched to the max (as you want to avoid background nebulosity as much as possible). Like so;

Phase1

Setting the saturation and stretch back to a more normal level shows this;

Phase2

And this is the background model APP calculated, it looks nice and gradual, also indicating the model is likely to be correct;

LPC Model

If you get this, save that as fits and then you can reload and try to make it even a bit better by doing the same. And then stretching more also makes for a nicer image.


ReplyQuote
(@skanker)
Main Sequence Star Customer
Joined: 4 years ago
Posts: 86
Topic starter

@wvreeven

First thanks for your help Wouter. It is not a mosaic but a single image (180x60sec.).

The black border was probably caused by the clip filter (Optolong L-Pro).



@vincent-mod

Also thanks for your help Vincent. That should be LPC on the highest level 🙂

I always take pictures in my garden but i have never had such gradients. Do you have any idea where these spots of color could come from?



CS



Gernot


ReplyQuote
(@wvreeven)
Galaxy Admin
Joined: 4 years ago
Posts: 1782


@skanker A sorry, I seemed to have remembered that it was a mosaic but clearly I was wrong. Great pic by the way!


Skanker liked
ReplyQuote
(@vincent-mod)
Quasar Admin
Joined: 5 years ago
Posts: 4919


@skanker

Thanks! Well to me this looks like you had a light source in the corner. The model APP calculated (that 3rd picture above) is a likely good representation as to where that source came from. Maybe a light of the neighbors or a bit more in the distance on that side? The color patches, I'm not an expert in why those become stronger, but I can imagine this to also happen with light pollution and an RGB sensor.


ReplyQuote
(@vincent-mod)
Quasar Admin
Joined: 5 years ago
Posts: 4919


I had a bit of extra play with post processing, correcting the colors a little, adding a bit of contrast, minor crop of the edges etc. It's definitely nice data for just 60 second exposures!

Taurus 105mm lpc cbg mod St

ReplyQuote
(@skanker)
Main Sequence Star Customer
Joined: 4 years ago
Posts: 86
Topic starter

@vincent-mod

Thank you for your efforts Vincent! Your input helped me a lot. I will post my results here in the next few days 🙂



CS



Gernot


ReplyQuote
(@skanker)
Main Sequence Star Customer
Joined: 4 years ago
Posts: 86
Topic starter

Hello @Vincent-mod & @wvreeven



Here is my final (!?) result:

Taurus Web



Full resolution and infos can be found here: https://www.astrobin.com/1c0jx0/?nc=user

I look forward to your feedback 🙂



CS



Gernot




ReplyQuote
(@wvreeven)
Galaxy Admin
Joined: 4 years ago
Posts: 1782


That is a stunning image. Congratulation!


Skanker liked
ReplyQuote
(@vincent-mod)
Quasar Admin
Joined: 5 years ago
Posts: 4919


Very nice, great detail you got out of the background! Maybe a bit bright on the 7 sisters?


Skanker liked
ReplyQuote
(@skanker)
Main Sequence Star Customer
Joined: 4 years ago
Posts: 86
Topic starter

@vincent-mod

Thx 🙂 Its not the final version of the picture ! I will collect a bit more feedback and then work it into the picture.

CS

Gernot
