The Cygnus Wall Complex

9 Posts
3 Users
7 Reactions
2,973 Views
(@gideon96)
Neutron Star
Joined: 6 years ago
Posts: 65
Topic starter
CygWall SHO web

The Cygnus Wall Complex in the North America Nebula (NGC 7000)

Around 1,500 Light years away, spanning 20 Light years wide, this massive complex of hot gasses and dust is a cosmic nursery for new Stars.

Shot in Dual-Band (Optolong L-eXtreme)
Edit in SHO style, using @thecoldestnights 's formula.

65 frames of 300 sec. each
Gain 100 / -5c

ZWO ASI2600 / GSO RC6 / TS Optics CCD47 x0.67 Reducer
ASIAIR PRO / iOptron GEM45
ZWO ASI290MM / ZWO OAG

AstroPixelProcessor: Calibrate, register, extract Ha/Oiii algorithm(worked like a charm!).
Pixinsight: Combine channels, stretch, curves and additional enhancing
PS: Annotate, export

Har Ha'Negev, Israel (Bortle 3)

Astrobin: https://astrob.in/6axp8o/0/






artem, Andy Booth and ah reacted
ReplyQuote
(@Anonymous 174)
Joined: 9 years ago
Posts: 5702


Very nice signal, maybe a bit too dark in the background?




ReplyQuote
(@gideon96)
Neutron Star
Joined: 6 years ago
Posts: 65
Topic starter

@vincent-mod
Thank you!

Hmm, this might be a screen cal/difference issue? I mean, it's not clipped for sure...
I still see the BG differences and features.




ReplyQuote
(@Anonymous 174)
Joined: 9 years ago
Posts: 5702


Sorry for the delay. Yes partly, if it's not clipped that is good indeed. I personally simply prefer a slightly brighter background, but it's a great result nonetheless!




ReplyQuote
(@gideon96)
Neutron Star
Joined: 6 years ago
Posts: 65
Topic starter

@vincent-mod



Yes of course, we all have our creative differences 🙂
The lower part of the photo below the "wall" is always brighter, the upper part is always darker, since it's kind of "blocked out".

I wanted something a bit dramatic, since the wall is very emphasized, and bold... That's partly why I went for gentler tones, less saturation, since the structure itself was very pronounced already.

This is for example, an early "playing around" version:




ReplyQuote
(@Anonymous 174)
Joined: 9 years ago
Posts: 5702


Totally, I definitely get your idea as well and I do like it. 🙂




Gideon Golan reacted
ReplyQuote
(@gideon96)
Neutron Star
Joined: 6 years ago
Posts: 65
Topic starter

Re-process, from stacking (with the new v2 beta), Ha-Oiii algorithm to Ha than Oiii

A brighter version, (@vincent-mod remembered you preferred it 🙂 )

CygWall Web

link to new revision: https://astrob.in/6axp8o/C/




Andy Booth reacted
ReplyQuote
(@mabula-admin)
Universe Admin
Joined: 9 years ago
Posts: 5363

Posted by: @gideon96

Re-process, from stacking (with the new v2 beta), Ha-Oiii algorithm to Ha than Oiii

A brighter version, (@vincent-mod remembered you preferred it 🙂 )

CygWall Web

link to new revision: https://astrob.in/6axp8o/C/

Beautiful result Gideon @gideon96 ! Thanks for sharing 🙂 !






Gideon Golan reacted
ReplyQuote
(@Anonymous 174)
Joined: 9 years ago
Posts: 5702


@gideon96 Yeeees, me like! 😉




Gideon Golan reacted
ReplyQuote
