Stacking images from different sources?

Page 1 / 2
  RSS

 Gary
(@garyrmck)
White Dwarf Customer
Joined: 4 years ago
Posts: 15
July 11, 2017 01:48

Hi Mabula,

I've been trying out APP with the limited amount of data I have available to me and getting excellent results, but I have a question - primarily because I don't have the data to try it!

Can APP process/stack data from different scope and camera combinations? Let's say tonight I use my 8" f4 newt to get some data, and next week I use my C11 at f7, one using a one shot color camera, the other a mono these be stacked in APP?

I'm looking at this to get fast low res color data, combined with high detail long focal length removed link

cheers

Gary


ReplyQuote
(@mabula-admin)
Universe Admin
Joined: 4 years ago
Posts: 2641
July 11, 2017 10:20

Hi Gary,

Thank you for your question.

Can APP process/stack data from different scope and camera combinations? Let's say tonight I use my 8" f4 newt to get some data, and next week I use my C11 at f7, one using a one shot color camera, the other a mono these be stacked in APP?

Yes, APP actually is very good at this. The registration engine of APP has no problem at all with combining data of different image scales and/or focal lengths and/or Field of Views. I have created a long video tutuorial to demonstrate this using data of 5 different optical configuration of 5 different photographers:

https://www.astropixelprocessor.com/registration-normalization-integration-using-ddc-lnc-mbb/

In the video, you can clearly see that there is a big difference in image scale between the different datasets of the different photographers.

Regarding combination of RGB and monochrome data. In 2) Calibrate, you can save your calibrated frames splitted per channel. Then you can register and integrate them with the monochrome channels. And with the "RGB combine" tool, you can put everything together 😉

Let me know if you have more questions.

Cheers,

Mabula




ReplyQuote
 Gary
(@garyrmck)
White Dwarf Customer
Joined: 4 years ago
Posts: 15
July 12, 2017 07:15

Thanks Mabula,

APP looks better and better....

cheers

Gary


ReplyQuote
(@mabula-admin)
Universe Admin
Joined: 4 years ago
Posts: 2641
July 12, 2017 08:50

You're welcome Gary,

Thanks 😉

Mabula


ReplyQuote
 Ron
(@rojoyinc)
White Dwarf Customer
Joined: 4 years ago
Posts: 24
September 30, 2019 17:48

Old topic, but I'm new to app.  Moved over from PI (which is way to many steps and clicks but surely very capable). I've enjoyed the automation of APP.

So - I shot some 6" APO shots of the ghost nebula. (200+ frames).  I later changed to the 11" rasa.  I shot some more.  I'm trying to intergrate all as APP says it can. I watched a nicely done video showing 5 photographers images and it seemed to be fairly fast.

My two scopes (same camera) has been churning now for over 24 hours and sits at 57%.  I have a 4 core CPU (app says it's using 3).
Is this typical speed?  There are only 2 different image scales - once it figured out the match - shouldn't it try that first on all other images?

Oh I'm doing the registration. Here's what I see after 24 hours.           (my fear is I have something set wrong and after 24+ hours it doesn't work) = (
On a good note, like the video it shows that the RMS is at least lowering slowly each time.

app




ReplyQuote
(@jochen-scharmann)
White Dwarf Customer
Joined: 2 years ago
Posts: 13
September 30, 2019 20:09

Hi Ron,

Hold On! if you selected multiple iterations, this process may last very long. With some 200 subs it took like 6-8 hours on my 8-core i7. Usually 1 iteration will do, but employing different focal lengths like you do, it might need 3 iterations and lots of patience. It will pay out in the end.

clear skies,

jochen


ReplyQuote
 Ron
(@rojoyinc)
White Dwarf Customer
Joined: 4 years ago
Posts: 24
September 30, 2019 23:46

OK THANKS for the fast reply. I did abort it before. Tried again and still long... I didn't pay attention to iterations. I assumed that was default. But I'll watch it next time.  I'll let it cook over night again tonight.  If they all stack it will be worth 48 hours.  It's in the bg - so as long as I don't crash it will be fine.  thanks!




ReplyQuote
 Ron
(@rojoyinc)
White Dwarf Customer
Joined: 4 years ago
Posts: 24
September 30, 2019 23:53

re-read you said IF?  I didn't change it.

looking =- I checked what Mabula checked in the video.

Quad
1
5
FLIP since one is a APO the other a RASA assuming 1/2 are flipped
Use dynamic dist.
SAME CAMERA OPTICS  unchecked  (different optics - same camera)

mode normal
reg model projective

rectilinearprojection
1.0
lanczos-3
no over under -
I don't see iterations?


ReplyQuote
(@vincent-mod)
Universe Admin
Joined: 4 years ago
Posts: 3550
October 1, 2019 11:08

Hi Ron, so 3 cores isn't a lot and having a lot of data with different scopes will take a lot of time in that case. It might be better to split up the data from the scopes and keeping the amount of frames in 1-go to about 150-200.


ReplyQuote
(@cwm2col)
Red Giant Customer
Joined: 7 months ago
Posts: 52
June 8, 2021 00:44

Reviving this thread instead of starting a new one.

When stacking multiple sessions using two different cameras but same optics, how do I feel with two different Bayer patterns?

One has BGGR (ToupTek) and the other is rggb (asi2600mc).

I would like to process the whole lot together.

Thanks


ReplyQuote
(@wvreeven)
Galaxy Admin
Joined: 3 years ago
Posts: 905
June 8, 2021 01:15

@cwm2col Hi Colm, it depends.

Is the Bayer info available in the FITS header? If yes then you can load the images in two different sessions and integrate them. In tab 6 you can choose to create one integration for each session or one integration for all sessions together.

If the Bayer info is not available in the FITS headers (for instance when you use APP) then you'll need to integrate the two sessions separately in two different integration runs. Then you can load the two integration results as lights and combine them.

HTH, Wouter


ReplyQuote
(@cwm2col)
Red Giant Customer
Joined: 7 months ago
Posts: 52
June 8, 2021 08:27

Of course, I knew this but forgot 😆 Thanks for the reminder and the help Wouter. I'll check if the ToupTek stores info in the fits file, I know the ZWO does


ReplyQuote
(@cwm2col)
Red Giant Customer
Joined: 7 months ago
Posts: 52
June 8, 2021 08:53

My ToupTek does not store fits info correctly, and labels a GRBG j stead of BGGR (an older driver problem).

So, it might be time to test the fits header editor feature on the latest APP release to make it work with the 'supported' debayering/CFA option for multiple session integration


ReplyQuote
(@vincent-mod)
Universe Admin
Joined: 4 years ago
Posts: 3550
June 8, 2021 09:18

That might work (didn't try it myself yet 🙂 ), or you process as separate sessions still. But let us know how it works!


ReplyQuote
(@cwm2col)
Red Giant Customer
Joined: 7 months ago
Posts: 52
June 15, 2021 17:10

@vincent-mod



Just getting time now to try this.

But, a persistent problem is that the byer patterns under 'supported' in tab 2 (read from fits header) says GBRG for all fields from both cameras, and always did that for all versions of APP I have used.

Can that be fixed? BAYERPAT and COLORTYP say RGGB for ASI2600 (correct) and BGGR for the touptek (correct). APP only says GBRG when all are loaded, under the CFA column in the text groups at the bottom of the app display. Anyone noticed this before?



I will try rewriting the touptek ones, but it should not be necessary to rewrite any of them if the bayer pattern is identified in the FITS header (assume reading direction such as bottom-up is the same for both). Maybe I am missing something?

Clipboard01




ReplyQuote
(@cwm2col)
Red Giant Customer
Joined: 7 months ago
Posts: 52
June 15, 2021 17:29

Fyi, the batch CFA modifier tool works perfectly. But, to get it to work, the images must be first loaded with the correct force bayer pattern and then batch modified so that it looks the correct color on the screen.

Then all files from different bayer pattern cameras can be loaded under 'supported' and 'force CFA' in tab 2 for subsequent processing.


ReplyQuote
(@vincent-mod)
Universe Admin
Joined: 4 years ago
Posts: 3550
June 15, 2021 21:45

Ok, thanks for that. So does that mean you got it working or that you still have this issue like in the comment above?


ReplyQuote
(@cwm2col)
Red Giant Customer
Joined: 7 months ago
Posts: 52
June 16, 2021 20:16

No. Still the same problem. No matter how many lights I load from any camera, irrespective of whether I choose supported or a particular bayer pattern in tab 2 and force CFA, the default pattern in the file list at the bottom of the screen is always GRBG.

Forcing CFA to the known pattern will allow it to show with correct colors on screen and subsequent processing, but I would like to see this problem fixed though. Right now it does not read the fits header correctly and ignores the bayer pattern of all cameras. It has to be known and forced, making it impossible to use data from two different camera with different bayer patterns using the 'supported' option. that would be very useful, especially for different systems, optics, cameras for collaborative mosiacs for instance.

They need to be processed separately at the moment, which is not so good for rejection and weighting of a large multisession stack, in some instances.

For the CFA fits header modification, that does work but it is not so intuitive. An image needs to be loaded first with force CFA option so that the color on the screen for the image is correct (again 'supported' option does not work initially). Then the batch fits header modifier works fine.  I think the nice tool tips for the new changes would be helpful, these are not implemented fully in the newer version. Maybe we might see them soon.



Thanks again, Colm


ReplyQuote
(@vincent-mod)
Universe Admin
Joined: 4 years ago
Posts: 3550
June 17, 2021 09:53

Alright, I'll pass this on to Mabula as I'm also not sure why the pattern would change in your case. Thanks for letting us know!


ReplyQuote
(@mabula-admin)
Universe Admin
Joined: 4 years ago
Posts: 2641
June 25, 2021 15:32

Hi Colm @cwm2col, @vincent-mod,

I need to really see this myself I think.... but

First of all, if the files have the BAYERPAT tag in the header, then all should work. APP also supports the tag CFAPAT and our own tag CFAIMAGE.

Then, the fits tag COLORTYP is not standard for a CFA pattern,  it is not in the FITS specification as well, and we don't support it (yet). I just checked. We can support it however if you can upload some frames with that tag.

The frames with the COLORTYP tag can be corrected in 1.083-beta2 with the Batch modify FITS tool.

If you leave the bayer pattern in 0) RAW/FITS to supported, it will use a supported tag in the header when present. Now the COLORTYP frames then will not work, because that is unsupported for now.

If you set the Bayer Pattern to anything else than supported, it will always overrule the header tag as it should.

Finally, if you set FORCE BAYER CFA, then the COLORTYP frames will be demosaiced with the set pattern. If the pattern was supported, it falls back to RGGB as the default, since most sensors have that pattern.

I would think that all your problems are caused by this unsupported COLOTTYP tag.

To make sure that we solve this, can you upload frames for both camera's so I can have a good look?

Upload can be done here:

https://upload.astropixelprocessor.com/

username and password: upload5

Please make a foilder with your name and let us know when uploaded 😉

Mabula




ReplyQuote
